General
Brand: Rosewill
Model: HP1-J800GD-F12S

Details
Type: ATX12V v2.31 & EPS12V v2.92
Maximum Power: 800 W
Fans: 1 x 120 mm
PFC: Active
Main Connector: 20 4Pin
12V Rails: Single
PCI-Express Connector: 2 x 6-Pin, 2 x 6 2-Pin
SATA Power Connector: 4
SLI: SLI Ready
CrossFire: CrossFire Ready
Modular: Full Modular
Power Good Signal: 100-500ms
Hold-up Time: 16ms min.
Efficiency: Up to 90%
Energy-Efficient: 80 PLUS GOLD Certified
Input Voltage: 100 - 240 V
Input Frequency Range: 50/60 Hz
Output: 3.3V@22A, 5V@22A, [email protected], [email protected], 5VSB@3A
MTBF:>100,000 Hours
Approvals: cTUVus, FCC certified
Max PSU Length: 140 mm
Connectors: 1 x 20 4-Pin Main Connector1 x 4 4-Pin ATX12V/EPS12V Connector2 x 6 2-Pin PCI-E Connector2 x 6-Pin PCI-E Connector4 x SATA Connector4 x 4-Pin Peripheral Connector1 x 4-Pin Floppy Connector

Dimension & Weight
Dimensions: 3.40" x 5.90" x 5.50"
